OPTIONS

The company offers several options that can be added to the Probe4Light system.

Clamping flange

Bride de serrage The clamping flange keeps the Probe4Light in position for a more precise measurement reproducibility.

The clamp can be held on an optical rod or table by means of a 4.3 mm diameter hole or 2 M6 holes.

Small model diffuser

Diffuseur petit modèle A small diffuser makes it possible to homogenize the light signal. This is connected to the Probe4Light via an optical fiber.

This allows the Probe4Light system to be moved from the measurement area.

The inlet diameter of the diffuser is 7.5 mm.

Large model diffuser

Diffuseur grand modèle The diffuser consists of an opal of 20 mm diameter. Its large photosensitive surface makes it possible to homogenize the light signal.

The large model diffuser interfaces directly with the Probe4Light system.

The inlet diameter of the diffuser is 20 mm.

Integral sphere

Sphère intégrante 2Sphère intégrante The integration sphere has an internal diameter of 30 mm and includes a barium sulphate coating to diffuse the light. The sphere makes it possible to trap and homogenize the total flux emitted by the light source.

The inlet port of the sphere is 7 mm in diameter. The integral sphere interfaces directly with the Probe4Light system.

A version of the integrating sphere exists with a small spout-shaped spout to reduce stray light and make measurements in a given smaller direction.

Optical fiber

Fibre optique An optical fiber can be ordered as an option with the Probe4Light, which allows the system to be deported or directly connected to a test device composed of an SMA905 connector.

The length of the optical fiber is 1 meter, but this length can be modified on specific request.
